FCSL105A
Wildlife Step Light with Amber Light
Using minimum 560nm wavelength amber LED to preserve nature, the
FCSL105A
Step Light is U.L. listed for exterior wet locations and approved by the Florida Fish & Wildlife Conservation Commission for use in areas where wildlife habitats exist. Housing and faceplate are marine grade, corrosion resistant, heavy walled, high pressure die cast aluminum construction with (2) 7/8" KO. Lens is 1/8" thick, tempered, heat resistant glass. Precision formed, reflector for maximum reflectance. Comes in Black and Bronze and available in dark matte, custom color finishes. Standard polyester powder coat finishes include black, bronze, silver and white with custom or RAL colors also available.
IES
IES Downloads
WILDLIFE_IES_Data.zip
Install Instructions
Install Instructions Downloads
FCSL100ii.pdf
Spec Sheet
Spec Sheet Downloads
FCSL105A.pdf
FEATURES & BENEFITS
Performance
71 lm (10.5W Max) Amber
Mounting Options
Wall Mount Brick Light
Power Input
UNV 120 - 277 VAC
Protection
IP65 Rated
Warranty
5-Year Limited Warranty
