FCBT690SA
24"H Wildlife Aluminum Bollard with Amber Light
Using a minimum 560nm wavelength amber LED to preserve nature, the FCBT690SA Bollard is Marine Grade, corrosion resistant, heavy walled aluminum. Tower body is extruded aluminum, 24-inch standard (specify custom height when ordering). Lens is clear, polycarbonate. Neoprene continuous closed cell gasket to seal out contaminants. Captive and recessed stainless steel, tamper resistant hex socket screws. Mounting insert sets base flush to surface. Heavy gauge base bracketing for bollard installation. FCBT690SA has a true AMBER LED option which uses AllnGaP chip technology to produce amber color with spectral control between 590-600nm above the 560nm required by Florida Fish & Wildlife Conservation Commission (FWC). Standard polyester powder coat finishes include black, bronze, graphite grey, silver and white with custom or RAL colors also available.
IES
Install Instructions
Install Instructions Downloads
Spec Sheet
Spec Sheet Downloads
FCBT690SA
FCBT690SA
FCBT690SA
FCBT690SA
FCBT690SA
FCBT690SA
FCBT690SA
FCBT690SA
FCBT690SA
FCBT690SAFCBT690SAFCBT690SAFCBT690SAFCBT690SAFCBT690SAFCBT690SAFCBT690SAFCBT690SA

FEATURES & BENEFITS


Performance
500 lm (13W Max) Amber

Mounting Options
Base plate with anchor bolts (included)

Power Input
UNV 120 - 277 VAC

Protection
IP65 Rated

Warranty
5-Year Limited Warranty
