FCBT690S
24" High Aluminum Bollard
FCBT690S Bollards are part of the FCBT690 family in a garden size. Marine grade, corrosion resistant, heavy walled aluminum. Tower body is extruded aluminum, 24-inch standard and packed with a 28 foot beam spread and 11 foot forward throw. Impact resistant polycarbonate lens. Neoprene continuous closed cell gasket to seal out contaminants. Captive and recessed stainless steel, tamper resistant hex socket screws. Mounting insert sets base flush to surface. Base is anchored through with a set of four 8" length x 3/8" diameter hot dipped bolts. Standard polyester powder coat finishes include black, bronze, graphite grey, silver and white with custom or RAL colors also available.
IES
IES Downloads
Install Instructions
Install Instructions Downloads
Spec Sheet
Spec Sheet Downloads
FCBT690S
FCBT690S
FCBT690S
FCBT690S
FCBT690S
FCBT690S
FCBT690S
FCBT690S
FCBT690S
FCBT690SFCBT690SFCBT690SFCBT690SFCBT690SFCBT690SFCBT690SFCBT690SFCBT690S

FEATURES & BENEFITS


Performance
765 lm (14W Max)

Mounting Options
A thick die-cast base plate is provided and anchored through with a set of four 8" length x 3/8" diameter hot dipped anchor bolts. Heavy gauge base bracketing for bollard installation.

Power Input
UNV 120 - 277 VAC

Protection
IP65 Rated

Warranty
5-Year Limited Warranty
